BK Precision 8500 User Manual

Byte
offset
Meaning
5 Upper low byte of maximum voltage.
6 Upper high byte of maximum voltage.
7-24 Reserved
Example: Suppose you want to set the maximum voltage to 16.23V. Since 1 represents 1mV,
therefore 16.23V translates to 16,230 in decimal. With 4 bytes in Hex, that would be 0x0003F6A.
Since the bytes are ordered in little-endian format, 0x6A would be the 3
rd
byte, 0x3F the 4
th
byte,
0x00 as 5
th
byte, and 0x00 as the 6
th
byte.
0x23 Read the maximum voltage allowed
Byte
offset
Meaning
3 Lower low byte of maximum voltage. 1 represents 1 mV.
4 Lower high byte of maximum voltage.
5 Upper low byte of maximum voltage.
6 Upper high byte of maximum voltage.
7-24 Reserved
0x24 Set the maximum current allowed
Byte
offset
Meaning
3 Lower low byte of maximum current. 1 represents 0.1 mA.
4 Lower high byte of maximum current.
5 Upper low byte of maximum current.
6 Upper high byte of maximum current.
7-24 Reserved
Example: Suppose you want to set the maximum current to 3.12A. Since 1 represents 0.1mA,
3.12A translates to 31,200 in decimal. With 4 bytes in Hex, that would be 0x000079E0. Since the
bytes are ordered in little-endian format, 0xE0 would be the 3
rd
byte, 0x79 the 4
th
byte, 0x00 as 5
th
byte, and 0x00 as the 6
th
byte.
0x25 Read the maximum current allowed
Byte
offset
Meaning
3 Lower low byte of maximum current. 1 represents 0.1 mA.
4 Lower high byte of maximum current.
8500 DC Load Series Version: February 4, 2009 Page 53 of 76

BK Precision 8500 Specifications

General

Maximum Power	150 W
Current Range	0-30 A
Load Modes	CC, CV, CR, CP
Input Voltage	100-240 VAC, 50/60 Hz
Voltage Resolution	1 mV
Current Resolution	1 mA
Ripple and Noise (CV)	≤ 10 mVrms
Operating Temperature	0°C to 40°C
Storage Temperature	-10°C to 70°C
Interface	RS232
Display	VFD
Voltage Accuracy	0.05% + 5 mV
Current Accuracy	0.1% + 10 mA
Ripple and Noise (CC)	10 mA rms
