OPERATING INSTRUCTIONS
Data Hold
This data hold function allows the operator to freeze the display. To
enter this mode, press the “HOLD” pushbutton; press again to release.
Static Recording
Press the “
REC
” pushbutton for more than one second to enter the static
recording mode. The maximum and minimum readings are then stored
in memory, while a beeping tone is produced when a new tested value
has been recorded. Push the same button to cycle through the
maximum, minimum and average of the present readings. The
MAX
,
MIN
or
AVG
indicators will display on LCD will turn on to indicate
what value is being displayed. Whenever the “
MAX AVG MIN
”
indicators appear on the LCD simultaneously, the display reading is
always a present value.
To exit this mode, press and hold the pushbutton for more than one
second.
Notes:
1. Static recording captures only stable values and updates the memory;
it will not record any “
OL
” (overload) value for any of the
L/C/R
functions. In addition, the meter will not record which values are
below 50 counts in Capacitance measurement.
2. Static recording is only available in manual ranging; however,
activation while in auto-ranging will automatically set meter to
manual ranging and cause calibration prompts to be displayed in the
recommended ranges.
Dissipation Factor / Quality Factor/ Phase Angle
The “
D/Q/Θ
” value can be displayed interchangeably by pressing the
“
D/Q/Θ
” button when the meter is set to Inductance or Capacitance
mode. It does not apply to resistance measurement. The phase angle is
available on Model-A only.
