Page #20 background imageLoading...
Page #20 background image
ServSwitch Freedom
724-746-5500 | blackbox.com
Page 20
Table 4-1. Configuration menu options
Letter Number Description
B Enter the OPTIONS port Baud rate menu
1 1200 (default)
2 2400
3 9600
4 19200
5 38400
6 57600
7 115200
F Enter the Functions menu
1 Show current firmware version
8 Reset configuration to factory defaults ( is displayed momentarily)
H Enter the Hotkey menu
1 Ctrl + Alt (default)
2 Ctrl + Shift
3 Alt + Shift
4 Right Alt
5 Alt
6 Left Ctrl + Alt
7 Right Ctrl + Alt
8 Hotkeys disabled
P Set a new password for use with the lock mode
S Enter the Switch Mode menu
1 All (default)
2 KVM + Speaker
3 KVM only
4 Speaker only
5 USB1 only
6 USB2 only
U Enter the User Preferences menu
1 Enable mouse switching (default)
2 Disable mouse switching
7 Cycle all ports (when using ‘Hotkey + Tab’ or ‘Autoscan’) (default)
8 Cycle only active ports (when using ‘Hotkey + Tab’ or ‘Autoscan’)
