ENGLISH
(Original instructions)
When using any tool for prolonged periods ensure you
take regular breaks.
u Impairment of hearing.
u Healthhazardscausedbybreathingdustdevelopedwhen
usingyourtool(example:-workingwithwood,especially
oak, beech and MDF.)
Vibration
Thedeclaredvibrationemissionvaluesstatedinthetechnical
dataandthedeclarationofconformityhavebeenmeasuredin
accordancewithastandardtestmethodprovidedbyEN62841
and may be used for comparing one tool with another. The
declaredvibrationemissionvaluemayalsobeusedina
preliminary assessment of exposure.
Warning!Thevibrationemissionvalueduringactualuseof
thepowertoolcandifferfromthedeclaredvaluedepending
onthewaysinwhichthetoolisused.Thevibrationlevelmay
increaseabovethelevelstated.
Whenassessingvibrationexposuretodeterminesafety
measuresrequiredby2002/44/ECtoprotectpersonsregularly
usingpowertoolsinemployment,anestimationofvibration
exposure should consider, the actual conditions of use and the
way the tool is used, including taking account of all parts of the
operating cycle such as the times when the tool is switched off
and when it is running idle in addition to the trigger time.
Labels on tool
The following symbols are shown on the tool, along with the
date code:
:
Warning!Toreducetheriskofinjury,theuser
must read the instruction manual.
Electrical safety
#
This tool is double insulated; therefore no
earthwireisrequired.Alwayscheckthatthe
powersupplycorrespondstothevoltageon
the rating plate.
u If the supply cord is damaged, it must be replaced by the
manufactureroranauthorisedBLACK+DECKERService
Centreinordertoavoidahazard.
Features
This tool includes some or all of the following features.
 1.On/offswitch
2. Dust extraction connector.
3. Base
4. Tip holder
5. Sanding base tip
6. Finger attachment*
7. Screw
8. Diamond shaped tip
In addition, this tool is supplied with some or all of the
followingaccessories:
Accessory Recommended application and use
Coarse grit
sandpaper
Fastpaint,varnishandrustremoval
Medium grit
sandpaper
Paint,varnishandrustremoval
Fine grit
sandpaper
Surfaceblendingandnishing
Extranegrit
sandpaper
Sanding between coats
Detail sanding tips Corners and hard to reach places
1OTpolishing/
stripping wool
Polishingmetals,strippingvarnish
and glass cleaning
Grey foam pad Applyingandremovingpolish
Rednon-woven
pad
Heavyscrubbingandrustremoval
Greyabrasive
paper
Polishing plastics
*Please Note:Thengerattachment(6)maynotbe
includedinallunits.Allaccessoriesareavailablefromyour
BLACK+DECKERdealerorviaourwebsite:
www.blackanddecker.co.uk
Assembly
Warning! Before assembly, make sure that the tool is
switched off and unplugged.
Fitting sanding sheets (g. A & B)
u Detach the two diamond-shaped tips (8) from the
sanding sheet (9).
u Hold the tool with the sanding base facing upwards.
u Place the sanding sheet (9) onto the sanding base,
making sure that the holes in the sheet line up with the
holes in the base.
Thediamond-shapedtip(8)canbereversedandreplaced
when worn.
u When the front part of the tip is worn, detach it from the
 sheet,reverseitandpressitontothesandingbaseagain.
u Whenthewholetipisworn,removeitfromthesanding
 baseandtanewtip.
u Thepolishingfoamandpads(14)canbettedthesame
way as the sanding sheets.
Tip of the sanding base (g. D)
When the sanding base tip (5) or tip holder (4) is worn, it can
bereversedorreplaced.Sparepartsareavailablefromyour
BLACK+DECKER dealer.
