20
Rear Camera Installation
Installation Method
3. Power cable arrangement and connection 4. Power cable connection and check the LED state
By using the cable holders, arrange the Cigar jack cable and
connect it to the DC IN port(upper hole). Check the recorded
image directly through LCD screen.
※ Power on after connecting rear camera cable.
Rear camera is not recognized if you connect power cable
after connecting rear camera cable.
After inserting the Cigar jack Power cable into cigar jack,
turn on the car ignition. If all LEDs of power status are on,
installation is completed.
