OBD Terminal Installation
Installation Method (※OBD Optional Components)
• Caution for the Installation of OBD
- Turn off the ignition first and then attach this device to a vehicle.
- The installation location is varied over vehicle model so it should be checked in advance.
• In case of installing it to another vehicle
- If this device is installed to another vehicle, it should be installed in the same way as the first installation .
- A vehicle model should be checked first. Then, change the setting upon a vehicle type.
• Installation Location by Vehicle Model
※ OBD terminal of vehicle (It should be attached here.)
3
2
1
List of available vehicle
models Reference
(Attachment)
SM3 New Model
4
SM5 New Model
SM7 New Model
5
To Next Page
