Fieldbus Manual
5-6
Setpoint status 1-4
Bits in this byte have the following meaning:
Bit no Function Comment
0
Setpoint 1 activated See description for setpoint function.
1
Setpoint 1 cycle done -“-
2
Setpoint 2 activated -“-
3
Setpoint 2 cycle done -“-
4
Setpoint 3 activated -“-
5
Setpoint 3 cycle done -“-
6
Setpoint 4 activated -“-
7
Setpoint 4 cycle done -“-
Status of digital inputs and outputs
Bits in this byte have the following meaning:
Bit no Function
0
Digital input 1 activated.
1
Digital input 2 activated.
2
Digital input 3 activated.
3
Digital input 4 activated.
4
Digital output 1 activated.
5
Digital output 2 activated.
6
Digital output 3 activated.
7
Digital output 4 activated.
Scale Error code
This register holds the error code for the scale. Normally this register should contain ‘000’
which means no error. Error codes 000 to 255 are valid in this register.
