LB-Hex User Manual Rev. B © 2017 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Width 11.2 in (284 mm)
Depth 4.5 inches (115.6 mm)
Height 10.6 inches (269.5 cm)
Weight 5 lbs (2.3 kg)
Power
Operating Voltage 100-240VAC, 50-60 Hertz
Power Consumption 109W, .92A, PF: .98
Light Source
LED 12*15-watt6-in-1RGBAW+UVLEDs
Optical
Beam Angle 25 degree beam
Luminous Intensity
Lux/m Red Green Blue Amber White UV All
1m 1,280 1,790 1,510 1,060 2,450 450 8,000
2m 410 580 480 330 750 170 2,360
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Control
Protocol USITT DMX-512
DMX Channels 6/11-channel
Input/Output 3-pin XLR Male/Female
Other Operating Modes Standalone, Master/Slave, Sound Active, Color Preset
Other Information
Another day, another six pointless words.
Warranty
2-year limited warranty, does not cover malfunction caused
bydamagetoLEDs.
Troubleshooting
Symptom Solution
Fixture Auto-Shut Off Checkthefaninthexture.Ifitisstoppedormovingslower
than normal, the unit may have shut itself off due to high
heat.Thisistoprotectthexturefromoverheating.
Beam is Dim Check optical system and clean excess dust/grime.
No Light Output Checktoensurextureisoperatingundercorrectmode,IE
soundactive/auto/DMX/Etc.,ifapplicable.
Chase Speed Too Fast/
Slow
Checktoensurepropersetupofspeedadjustment.
No Power Check fuse, AC cord and circuit for malfunction.
Slow Movement Verify that 220V/110V switch is in the correct position, if ap-
plicable. Also check that speed channels are set appropriately.
No Response to Audio Verifythatthextureisin“SoundActive”mode.
If your problem persists or isn’t listed, please open a support ticket
online at: www.blizzardlighting.com/support.
