LB-Hex User Manual Rev. B © 2017 Blizzard Lighting, LLC
Figure 1: The LB Hex™ Pin-Up Picture
12* 6-in-1
RGBAW+UVLEDs
Heavy-Duty
Composite Housing
Secure Grip
Locking Knobs
Figure 2: The Rear Connections
Power Out
DMX In DMX Out
Microphone
Power In
Mic Sensitivity Menu Display
Menu Buttons
Dual
Mounting
Brackets
