Blizzard Lighting LB HEX - Dimensional Drawings

Page 18
LB-Hex User Manual Rev. B © 2017 Blizzard Lighting, LLC
Dimensional Drawings
8.5 in (215 mm)
9.8 in (248.2 mm)
11.2 in (284 mm)
10.6 in (269.5 mm)
4.5 in
(115.6 mm)
