Blizzard Lighting LB HEX - Meet the LB Hex; DMX Quick Reference (11-Channel Mode); DMX Quick Reference (6-Channel Mode)

Page 5
LB-Hex User Manual Rev. B © 2017 Blizzard Lighting, LLC
2. MEET THE LB-PAR HEX
MAIN FEATURES
•12*highoutput15-watt6-in-1RGBAW+UVLEDs
• User selectable 6/11 DMX channels
• Full color mixing in standalone, master/slave and DMX modes
• Built-in automated & sound active programs via master/slave
• User selectable 8/32-bit dimming curve modes
• Durable, scratch resistant composite housing
ADDITIONAL FEATURES
• Lightweight and compact (It kept its New Years’ resolution!)
•4-buttonLEDcontrolpanelforeasyprogramming
•Dualbracketforexibilityinmounting
•Flicker-freeconstant-currentLEDdriver
• 3-pin male input and 3-pin female output
• PowerCon™ compatible AC power In/Out connectors
•CandirectlypowerthewiCICLE®wirelesssystemviaDMX
DMX Quick Reference (11-Channel Mode)
Channel What It Does
1 Dimmer (0% <-> 100%)
2 Red Intensity (0% <-> 100%)
3 Green Intensity (0% <-> 100%)
4 Blue Intensity (0% <-> 100%)
5 Amber Intensity (0% <-> 100%)
6 White Intensity (0% <-> 100%)
7 UV Intensity (0% <-> 100%)
8 Strobe (slow <-> fast)
9 Built-In Programs
10 Speed (slow <-> fast)
11 32-bit Dimming
DMX Quick Reference (6-Channel Mode)
Channel What It Does
1 Red Intensity (0% <-> 100%)
2 Green Intensity (0% <-> 100%)
3 Blue Intensity (0% <-> 100%)
4 Amber Intensity (0% <-> 100%)
5 White Intensity (0% <-> 100%)
6 UV Intensity (0% <-> 100%)
