ELECTRIC CONVECTION OVENS 2 INSTALLATION
DELIVERY AND LOCATION
DELIVERY AND INSPECTION
All Blodgett ovens are shipped in containers to prevent damage. Upon delivery of your new oven:
• Inspect the shipping container for external damage. Any evidence of damage should be noted on the delivery receipt
which must be signed by the driver.
• Uncrate the oven and check for internal damage. Carriers will accept claims for concealed damage if notied within
fteen days of delivery and the shipping container is retained for inspection.
The Blodgett Oven Company cannot assume responsibility for loss or damage suffered in transit. The carrier assumed full
responsibility for delivery in good order when the shipment was accepted. We are, however, prepared to assist you if ling
a claim is necessary.
OVEN LOCATION
The well planned and proper placement of your oven will result in long term operator convenience and satisfactory perfor-
mance. The following clearances must be maintained between the oven and any combustible or non-combustible construc-
tion.
OVEN CLEARANCES
Model Right Side Left Side Back Bottom
CTB/CTBR 0” (0cm) 0” (0cm) 0” (0cm) 0” (0cm)
Mark V-100 1” (2.5cm) 1” (2.5cm) 1” (2.5cm) 0.5” (1.3cm)
Mark V-200 0.5” (1.3cm) 0.5” (1.3cm) 0.5” (1.3cm) 0.5” (1.3cm)
SHO-100-E 0” (0cm) 0” (0cm) 0” (0cm) 0.5” (1.3cm)
Zephaire-100-E 0” (0cm) 0” (0cm) 0” (0cm) 0.5” (1.3cm)
Zephaire-200-E 0.5” (1.3cm) 0.5” (1.3cm) 0.5” (1.3cm) 0.5” (1.3cm)
Mark V XCEL 0” (0cm) 0” (0cm) 0” (0cm) 0.5” (1.3cm)
12” (30cm) must be available on all oven sides and back for servicing.
Keep the oven area free and clear of all combustibles such as paper, cardboard, and ammable liquids and solvents.
Do not place the oven on a curb base or seal to a wall. This will restrict the ow of air and prevent proper ventilation result-
ing in damage to the oven.
Before making any utility connections to this oven, check the rating plate to be sure the oven specications are compatible
with the electrical services supplied for the oven.
1. Pull out control panel. The rating plate attached to the inside of the control compartment.
