Blodgett MT1828E - Page 20

Installation
16
Electrical Connection
MT1828G
L1
N
L2
120
120
208-240
OvenSupply
MT1828E Single Phase
MT1828E Three P hase Delta System
L1
208/240
OvenSupply
L2
L1
L2
L3
208/240
OvenSupply
MT1828G
L1
N
220/240
OvenSupply
MT1828E Three P hase Delta System
MT1828E Three Phase WYE SystemMT1828E Single Phase
L1
220/230/240
OvenSupply
L2
L1
L2
L3
240/
220
OvenSupply
N
415/380
L1
L2
L3
208/240
OvenSupply
415/380
415/
380
U.S. and Canadian Installations
General Export and Australian Installations
Figure 13
