GENERAL SPECIFICATIONSGENERAL SPECIFICATIONS
Fuse # Relay # Amps Description
F16 N/A NOT USED
F17 K17 NOT USED
F18 N/A NOT USED
F19 K19 NOT USED
F20 N/A NOT USED
F21 N/A 10 DRVPWR
F22 N/A 10 Relay Power Source
F23 N/A 30 Available
F24 N/A 30 Available
F25 N/A 30 Available
F26 N/A 10 12 Volt to Cooling Fan Relays
F27 N/A 20 DC/DC Enable
F28 N/A 10 Cabin MPRD
F29 N/A 10 12 Volt for Interlocks
F30 N/A 20 Coolant Pump(s) Enable
Fuse # Relay # Amps Description
F31 N/A 10 12Volt Supply for Drive Motor Controller
F32 N/A 10 12 Volt to Electric Heater Controller
F33 N/A NOT USED
F34 N/A NOT USED
F35 N/A NOT USED
F36 N/A NOT USED
F37 N/A NOT USED
F38 N/A NOT USED
F39 N/A NOT USED
F40 N/A NOT USED
12 Volt Large Box Fuses (cont'd)
