Power Rake Operation and Maintenance Manual
Operation
Attachment Inspection
Daily Inspection
NOTE: Inspect the attachment by performing a
walk around daily before and after use.
Use the following inspection checklist as a
guideline.
Check the following items every 10 hours of
operation:
• Verify that the power rake is properly
connected to the machine.
• Check that all shields and guards are in place.
• Check hydraulic lines, connections and fittings
for hydraulic oil leaks. Repair or replace
damaged parts if necessary.
• Check the power rake mounting hardware for
wear or damage. Inspect the pins and mount
(on the attachment) for wear or damage.
Repair or replace damaged parts if necessary.
• Check that the rotor turns freely.
Weekly Inspection
Check the following items every 40 hours of
operation:
• Check rotor and rotor teeth for wear or
damage.
• Check all bolts for tightness.
• Inspect the power rake frame for cracks,
bends, or damage.
• Check for debris build up between rotor and
frame. Remove any debris build up.
Monthly Inspection
• Check the chain case oil.
• Check the drive chain tension.
• Check skid plates for wear.
• Check that all bolts are tight.
• Check rotor housing and rotor teeth for cracks
or damage. Replace if necessary.
• Check mounting plate hardware.
• Check power rake frame, shields, guards.
Repair if damaged or replace if necessary.
• Check for damaged or missing decals.
Replace if necessary.
• Check for damaged or leaking hydraulic hoses
or fittings. Replace if necessary.
• Lubricate as required.
WARNING
AVOID SERIOUS INJURY OR DEATH
Before servicing the attachment:
• Always park on a flat level surface.
• Lower lift arms and place attachment flat
on the ground.
• Place all controls in NEUTRAL.
• Engage the park brake.
• Wait for all moving parts to stop.
• Stop the engine and remove the key.
SEE MACHINE’S OPERATOR’S MANUAL
FOR ADDITIONAL INFORMATION.
