Power Rake Operation and Maintenance Manual
Specifications
Attachment Specifications
DESCRIPTION
POWER RAKE
72” 84” 96”
Overall Height 37 in. (940 mm) 37 in. (940 mm) 37 in. (940 mm)
Overall Length 64.5 in. (1638 mm) 64.5 in. (1638 mm) 64.5 in. (1638 mm)
Overall Length (Without
Gauge Wheels)
44 in. (1118 mm) 44 in. (1118mm) 44 in. (1118 mm)
Overall Width 81.25 in. (2064 mm) 93.25 in. (2369 mm) 105.25 in. (2673 mm)
Raking Width 72 in. (1829 mm) 84in. (2134 mm) 96 in. (2438 mm)
Full Angle Raking Width 67.66 in. (1719 mm) 78.93in. (2005 mm) 90.21 in. (2291 mm)
Minimum Hydraulic Flow 18 GPM (68 L/min) 18 GPM (68 L/min) 18 GPM (68 L/min)
Maximum Hydraulic Flow 39 GPM (148 L/min) 39 GPM (148 L/min) 39 GPM (148 L/min)
Drive System Chain Chain Chain
Drive Lubricant (or
equivalent)
80 / 90W 80 / 90W 80 / 90W
Weight 1223 lbs. (555 kg) 1248 lbs. (566 kg) 1273 lbs. (577 kg)
