38
Power Rake Operation and Maintenance Manual
Maintenance
Angle Will Not Hold Position.
Faulty manifold.
Contact Blue Diamond product
support.
Faulty solenoid. Repair or replace solenoid.
Rocks Are Being Left Behind.
Material bar out of adjustment. Adjust material bar.
Material bar rubber is worn. Replace material bar rubber.
Rocks Are Flowing Out From Front
Shields.
Over capacity.
Install optional skid plate.
Reduce travel speed.
Reduce engine speed.
Side Shield Allowing Material Out
Leaving Ridges.
Over capacity. Install optional skid plate.
Side Shields Are Bending. Over capacity. Install optional skid plate.
Material Bar Keeps Going Out of
Adjustment.
Slider plate is bent. Replace slider plate.
PROBLEM CAUSE SOLUTION
