Power Rake Operation and Maintenance Manual

Parts

ITEM DESCRIPTION PART # QTY

1 Wire Harness, 2-Pin Deutsch to 2-Pin Flat (not shown) 216956 1

2 Roller Chain Tensioner UHMW 232005 2

3 Tensioner Ears / Tabs 232010 2

4 Spring, Chain Tensioner 232015 1

5 Chain # 80 High Strength Connecting Link (Cotter Pin Style) 232020 1

6 Sprocket Drive #80 Single 14 Teeth 1-1/2” Bore (not shown) 232025 1

Rotor Bearing Chain Case R Bolt 1-1/2” Eccentric Collar

Bearing

232035 1

8 Bearing Insert only (not shown) 232040 1

9 Side Shield, Right 232100 1

10 Side Shield, Left 232105 1

11 Replaceable Tooth, 2” 232110 -

12 Hardened Jam Nut 232115 -

13 Spacer, Gage Wheel 232120 -

14 Lynch Pin 232125 1

15 Hydraulic Motor, V-Tec 6000 232600 1

16 Seal Kit Standard (High Pressure Seals) (not shown) 232605 1

232270 POWER RAKE SEVERE DUTY MATERIAL BAR 84"
