Specifications
Microphone and performance
Power Required/Consumption: 5V 150mA
Sample Rate: 48kHz
Bit Rate: 16bit
Capsules: 3 Blue-proprietary 14mm condenser capsules
Polar Patterns: Cardioid, Bidirectional, Omnidirectional, Stereo
Frequency Response: 20Hz – 20kHz
Sensitivity: 4.5mV/Pa (1 kHz)
Max SPL: 120dB (THD: 0.5% 1kHz)
Headphone Amplier
Impedance: >16 ohms
Power Output (RMS): 130mW
THD: 0.009%
Frequency Response: 15Hz – 22kHz
Signal to Noise: 100dB
Specications
Dimensions (extended in stand): 4.72” (12cm) x
4.92”(12.5cm) x 11.61”(29.5cm)
Weight (microphone): 1.2lbs (.55kg)
Weight (stand): 2.2lbs (1kg)
System Requirements
PC: Windows 7, Windows Vista, XP Home Edition
or XP Professional
USB 1.1/2.0; 64 MB RAM (minimum)
Macintosh: Mac OSX (10.4.11 or higher)
USB 1.1/2.0
64 MB RAM (minimum)
