Bluetti Sub Panel - Single EP500 Pro

- 09 -
Connection of single EP500Pro with Sub Panel
CRITICAL LOAD
NON-CRITICAL LOAD
POWER GRID
MAIN PANEL
POWER GRID
MAIN PANEL
SUB PANEL
POWER GRID
CRITICAL LOAD
NON-CRITICAL LOAD
3.1.2 Single EP500 Pro
Cable involved in the package of Sub Panel to connect with EP500Pro
solar power station.
Figure 3.5 Input Plug
(For EP500Pro)
Figure 3.6 Off-grid Output Plug
(For EP500Pro)
WARNING:
The Input and Load circuit have to be connected to the same Line Wire.
Figure 3.7 Main Panel Figure 3.8 Sub Panel & single EP500Pro
