Bluetti Sub Panel - Installation; Preparation

2.1 Preparation
2.2 Installation
- 03 -
2. Installation
2.1.1 Tool
Tools for installation of Sub Panel.
2.1.2 Wire
The wires connecting the home circuit to the Sub Panel are required as
the chart below. The length and size of the cables are determined accord-
ing to your needs and actual installation environment.
The cable for connecting AC300 or EP500 series with Sub Panel contained
in the package, please follow the instruction.
1) Take out the screw from the front cover of Sub Panel and remove it as
Figure 2.2.
WARNING:
The AC cable should meet the requirements of National Electrical
Standards.
No.
1
2
3
4
Tool
Drill
Screw（4 PCS）
Wire strippers/Bolt cutter
Screw Driver(1 Set)
Procedure
Preinstallation
Installation
Wire
Wire
Wire
Hot（L1）
Hot（L2）
Neutral（N）
Earth（PE）
Size (recommendation)
≥8 AWG
≥8 AWG
≥8 AWG
≥8 AWG
Color (recommendation)
Black
Black
White
Green
Figure 2.1.1 Tool Requirement
