226mm
226mm
540mm
540mm
533mm
533mm
- 04 -
Figure 2.2 Remove Front Cover
2) Drill into the wall according to the size of Sub Panel.
Type A - Mounting: 4PCS Expansion Screw for concrete wall, tapping
screw for wooden.
Type B - Hanging: 2PCS Expansion Screw for concrete wall, tapping screw
for wooden.
Figure 2.2.2 Drill & Mount
Figure 2.2.1 Drill & Mount
