Bluetti Sub Panel - Single AC300

- 10 -
Connection of single AC300 with Sub Panel
3.1.3 Single AC300
Cable involved in the package of Sub Panel to connect with AC300 solar
power station.
WARNING:
The Input and Load circuit have to be connected to the same Line Wire.
Figure 3.11 Main Panel Figure 3.12 Sub Panel & single AC300
Figure 3.9 Input Plug
(For AC300)
Figure 3.10 Off-grid Output Plug
(For AC300)
CRITICAL LOAD
NON-CRITICAL LOAD
POWER GRID
MAIN PANEL
POWER GRID
MAIN PANEL
SUB PANEL
POWER GRID
CRITICAL LOAD
NON-CRITICAL LOAD
