Bluetti Sub Panel - Dual EP500 Pro

- 12 -
3.2.2 Dual EP500 Pro
Cable involved in the package of Sub Panel to connect with Dual EP500-
Pro solar power station.
Figure 3.19 Main Panel Figure 3.20 Sub Panel & Dual EP500Pro
WARNING:
The Input and Load circuit have to be connected to the same Line Wire.
CRITICAL LOAD
NON-CRITICAL LOAD
POWER GRID
MAIN PANEL
POWER GRID
POWER GRID
CRITICAL LOAD
NON-CRITICAL LOAD
MAIN PANEL SUB PANEL
Figure 3.17 Input Plug
(For EP500Pro)
Figure 3.18 Off-grid Output Plug
(For EP500Pro)
