Bluetti Sub Panel - Dual AC300

- 13 -
3.2.3 Dual AC300
Cable involved in the package of Sub Panel to connect with Dual AC300
solar power station.
WARNING:
The Input and Load circuit have to be connected to the same Line Wire.
Figure 3.21 Input Plug
(For AC300)
Figure 3.22 Off-grid Output Plug
(For AC300)
Figure 3.23 Main Panel Figure 3.24 Sub Panel & Dual AC300
CRITICAL LOAD
NON-CRITICAL LOAD
POWER GRID
MAIN PANEL
POWER GRID
MAIN PANEL SUB PANEL
POWER GRID
CRITICAL LOAD
NON-CRITICAL LOAD
