Bluetti Sub Panel - Page 18

- 15 -
Socket 1 Socket 2 Socket 3 Socket 4
PE Bus Bar
NEUTRAL Bus Bar
0 21
G N
BOND WHEN REQUIRED
will not switch the floating neutral to bonded neutral. If you want to
convert the Sub Panel to bonded neutral, please connect the Sub Panel
with Main Panel, or follow the instruction to connect the Neutral bus-bar
to PE.
1 2
43
5 6
7 8
9 10
11 12
13 14
15 16
