40 BA-077/1EN M6X.20XX
Error Cause Solution Note
Drilled holes too
large, oval or rag-
ged
Drill diameter is too large Check drill bits none
Drill bits are twisted Replace drill bits none
Drill bits are dull Repoint drill bits or replace none
Head speed for drilling is too high Set proper head brake point See chapter 3
Drilling through work pieces Use roof tip drill bit to drill through none
Drill blockage in
wood
Improper material has been drilled Only use work pieces made from wood,
particle board or plastic coated wood
none
Head speed for drilling is too high Set proper head brake point See chapter 3
Drill bits are dull Repoint drill bits or replace none
Drill rotation not set properly Install counter clockwise drill bits into
chucks marked in red and clockwise drill
bits into chucks marked in black
none
6 - Troubleshooting
