39 BA-077/1EN M6X.20XX
6.2 - Error during vertical drilling
Error Cause Solution Note
Drilling depth does
not match
Drilling depth revolver is set to the
wrong position
Set the drilling depth revolver to the correct
work piece thickness
See chapter 3
Drill bits are set too short or too long Drilling length set to 57 mm See chapter 4
Drill bits not completely inserted into
the chuck
Clean dirt from chuck and completely
insert drill bit
See chapter 4
Work piece thickness does not cor-
respond to the given value (e.g. 15 mm
instead of 16 mm)
Check work piece thickness
Reset any stops on the revolver
none
See chapter 3
Machine is somehow running into an
object
Remove object none
Feed switch was released before the
drilling depth was reached
Keep feed switch engaged until the drilling
depth has been reached
none
Drillings are off
centre or in the
wrong position
The swivel stops were not set properly
on the ruler
Check the position of the stops and correct
if necessary
none
The ruler is not clamped or not clamped
cleaning
Make sure that the ruler is clamped
securely
none
There are chips between the ruler and
the work piece
Remove dirt and chips none
The work table is not set correctly Set work table to the correct position See chapter 3
Extension ruler is not attached properly Check ruler attachment and extension none
The work table was not clamped Secure work table with the clamping lever none
The work piece was placed on the ruler
properly and pressed to the stops
Make sure that the work piece is placed
properly on the ruler and to the stops
Use hold down clamp
none
Fittings cannot be
inserted or only
with great difficulty
The air pressure is too low Air pressure must be 6 bar none
Insertion ram or swing arm is running
up against an object
Check the position of the insertion ram
Check the drilling distance
none
The surface of the work piece is too
hard
Bevel drillings Use slip-on coun-
tersink
Drillings are not deep enough See point “Drilling depth not reached” none
The drilling diameters are too small Check drill bits and replace if necessary none
The insertion ram has shifted or turned Set insertion ram See chapter 4
The work piece has shifted Set the hold down clamp so that the it is
held secure
See chapter 3
6 - Troubleshooting
