41 BA-077/1EN M6X.20XX
6.3 - Error during horizontal drilling
Error Cause Solution Note
Drilling depth not
reached
Drilling depth was not set correctly Set correct drilling depth See chapter 3
Drilling length does not match Drilling length should be 77 mm none
Drill bits not completely inserted into
the chuck
Clean chuck and/or use cover caps if no
drill bits are inserted
none
The horizontal drilling unit is filled with
chips
Open horizontal drilling unit and remove
chips
none
Drilling position is
incorrect
The drilling distance is not set properly Correct setting, tighten clamping screw See chapter 3
The stops were not set properly on the
ruler.
Check the position of the stops and correct
if necessary
none
There are chips between the ruler and
the work piece and/or under the work
piece
Remove chips none
6 - Troubleshooting
