BLUM PRO-CENTER - E - EC Declaration of Conformity; EC Declaration of Conformity; Technical Data

8 BA-077/1EN M6X.20XX
E - EC Declaration of Conformity
E.1 - EC Declaration of Conformity
Julius Blum GmbH, Industriestr. 1, A-6973 Höchst herewith declare on our own responsibility that the product PRO-CENTER
(M60.20xx and M65.20xx) with drilling heads (MZK.2000, MZK.2100, MZK.2110, MZK.2200, MZK.2210, MZK.2230, MZK.2400,
MZK.2410, MZK.2800, MZK.2810, MZK.2880) to which this Declaration refers, complies with the following EC Directives:
EC Machine Directive 2006/42/EC
EC EMV Directive 2004/108/EC
The following harmonised European standards have been used to ensure proper
implementation of the requirements specified in the EU Directives:
EN ISO 12100-1, EN ISO 12100-2, EN 13849-1, EN 349, EN 983
In addition, the following standards have also been applied:
EN ISO 11202, EN ISO 11204, DIN 33893-2
Höchst, 06.07.09
Dipl.-Ing. Herbert Blum Documentation authorised agent:
Managing Director Dipl.-Ing. (FH) Thomas Maier
www.blum.com www.blum.com
E.2 - Technical data
General data:
• Voltage: see serial tag
• Current: see serial tag
• Power input:
Vertical motor: 1.1 kW
Horizontal motor: 0.5 kW
Stand By: 12 W
• RPM: see serial tag
• Compressed air: 5 - 7 bar
• Air consumption: 2 litres per cycle
Important
Provide a 16 A mains backup
fuse.
Weight and measurements:
a) PRO-CENTER without horizontal
drilling head
Weight: m= 75 kg
Dimensions: H= 890 mm
W= 1000 mm
D= 900 mm
b) PRO-CENTER with horizontal
drilling head
Weight: m= 95 kg
Dimensions:
H= 890 mm
W= 1000 mm
D= 1300 mm
Processing dimensions:
a) Vertical drilling head
• max. workpiece thickness: 40 mm
• Drilling distance
centre spindle: 5 - 124 mm
• Max.
drill diameter: 35 mm
b) Horizontal drilling head
• max. workpiece thickness: 30 mm
• Drilling height: 5 - 16 mm
• Drilling depth: max. 50 mm
• Max. drill diameter 10 mm
!
