LD6 AND MD8 BACKHOE BOX PARTS
5
The LD6 and MD8 box parts contains items needed to complete the assembling of the LD6 and MD8 Backhoe. Be
sure to check the contents of the box against the packing list in the box or against the parts list in this manual.
Backhoe Box Parts
ITEM DESCRIPTION QUANTITY
1 Step, Right 1
2 Step, Left 1
3 Grab Bar 1
4 Cotter Pin 3/16” x 1 ½” 10
5 Cylinder, Stabilizer 2
6 Pin Cylinder 1” x 3” 4
7 Guard, Stabilizer 2
8 Ties, Plastic Hose 5
9 Adaptor Fitting, SAE 6 O-Ring to JIC 6 Flare St. 10
10 Clamp, Insulated Hose 1” 6
11 Screw, Machine 3/16” x ¾” 6
12 Washer, Lock 3/16” 6
13 Nut, Hex 3/16” 6
To Next Page
