New Generation N62 Engine Chapter 3 P.47
Course Contents/Background Material
© BMW AG, Service Training
The VANOS units are supplied with oil via holes in the camshaft.
The oil holes are located on the left and right of the thrust
bearing.
Depending on the individual VANOS adjustment direction, the
VANOS is supplied with oil via either the rear oil ducts (1+2) or
the front oil ducts (3+4). The oils moves through the camshaft to
the VANOS units.
VANOS solenoid valves
The design of the VANOS solenoid valves is the same as those
in the N42 engine. The gasket is used only for the N62 engine.
