The engaged fuel filler cap
locks immediately when the
steering lock is locked or dur-
ing starting.
Securing motorcycle
for transport
Protect all component surfaces
against which straps are routed
against scratching. For exam-
ple, use adhesive tape or soft
cloths.
ATTENTION
Motorcycle tips to the side
when raising
Component damage cause by
tipping over
Secure the motorcycle against
tipping to the side, preferably
with the assistance of a second
person.
Push motorcycle onto transport
surface, and do not place on
side stand or center stand.
ATTENTION
Pinching of components
Component damage
Do not pinch components,
e.g. brake lines or wiring
harnesses.
Fasten front straps to both
sides of the handlebars.
Guide straps through leading
link and then tension.
6
112
z Riding

BMW R 1200GS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	125 hp (92 kW) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Tire	120/70 R 19
Rear Tire	170/60 R 17
Length	2, 210 mm
Width	953 mm
Height	1, 450 mm
Wheelbase	1, 507 mm
Fuel Capacity	20 liters
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Transmission	6-speed
Clutch	Hydraulically operated wet clutch
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminum single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual 305 mm discs, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston floating caliper
ABS	BMW Motorrad ABS (partly integral)
Seat Height	850 mm
Wet Weight	244 kg
