surface, always use a clean, dry
cloth to hold the light source.
Install light source 1 by turning
clockwise in light housing.
Insert inside end of lens into
light housing and close it.
Fit the screw 1.
Replacing LED tail light
The LED tail light can only be
completely replaced.
For details please contact
a specialist service facility,
preferably an authorized
BMW Motorrad Retailer.
Replace additional LED
headlight
with LED auxiliary headlight
OA
The LED additional headlights
can only be completely replaced;
it is not possible to replace indi-
vidual LEDs.
Please contact a specialized
workshop, preferably an autho-
rized BMW Motorrad retailer.
Jump-starting
ATTENTION
Current too high when jump-
starting the motorcycle
Cable fire or damage to the mo-
torcycle electronics
Do not jump-start the motor-
cycle using the power socket,
only via the battery terminal.
ATTENTION
Contact between crocodile
clips of jump leads and mo-
torcycle
Danger of short circuit
8
153
z Maintenance

BMW R 1200GS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	125 hp (92 kW) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Tire	120/70 R 19
Rear Tire	170/60 R 17
Length	2, 210 mm
Width	953 mm
Height	1, 450 mm
Wheelbase	1, 507 mm
Fuel Capacity	20 liters
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Transmission	6-speed
Clutch	Hydraulically operated wet clutch
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminum single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual 305 mm discs, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston floating caliper
ABS	BMW Motorrad ABS (partly integral)
Seat Height	850 mm
Wet Weight	244 kg
