BMW R 1200GS 2016 User Manual

Steering and ignition
lock
Keys
You are provided with 2 ignition
keys.
Should you lose your keys, re-
fer to the information regard-
ing the electronic immobilizer
(EWS) ( 49).
A single key fits the steering and
ignition lock, the fuel filler cap
and the seat lock.
with case
OA
with topcase
OA
The cases and the topcase can
also be ordered with locks for
the same key on request. Please
contact an authorized workshop
for this purpose, preferably an
authorized BMW Motorrad re-
tailer.
Locking handlebars
Turn handlebars to left.
Turn key to position 1 while
moving handlebars slightly.
Ignition, lights and all electrical
circuits switched off.
Handlebars are locked.
Key can now be removed.
Switching on ignition
Insert key into the steering and
ignition lock. Turn key to posi-
tion 1.
Parking lights and all function
circuits are switched on.
Pre-Ride-Check is carried out.
( 100)
ABS self-diagnosis is
performed. ( 100)
ASC self-diagnosis in progress.
( 101)
with Dynamic Traction Control
(DTC)
OE
DTC self-diagnosis is per-
formed. ( 102)
4
48
z Operation

BMW R 1200GS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	125 hp (92 kW) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Tire	120/70 R 19
Rear Tire	170/60 R 17
Length	2, 210 mm
Width	953 mm
Height	1, 450 mm
Wheelbase	1, 507 mm
Fuel Capacity	20 liters
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Transmission	6-speed
Clutch	Hydraulically operated wet clutch
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminum single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual 305 mm discs, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston floating caliper
ABS	BMW Motorrad ABS (partly integral)
Seat Height	850 mm
Wet Weight	244 kg
