BMW R 1200GS 2016 User Manual

Troubleshooting chart
Engine does not start.
Possible cause Remedy
Side stand extended and gear engaged Retract side stand.
Gear engaged and clutch not disengaged Place transmission in neutral or disengage clutch.
No fuel in tank Refueling procedure ( 109).
Battery drained Charging connected battery ( 155).
Overheating protection for starter motor has ac-
tivated. Starter motor can only be actuated for a
limited period.
Leave the starter motor to cool down for around 1
minute until it becomes available again.
11
184
z Technical data

BMW R 1200GS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	125 hp (92 kW) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Tire	120/70 R 19
Rear Tire	170/60 R 17
Length	2, 210 mm
Width	953 mm
Height	1, 450 mm
Wheelbase	1, 507 mm
Fuel Capacity	20 liters
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Transmission	6-speed
Clutch	Hydraulically operated wet clutch
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminum single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual 305 mm discs, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston floating caliper
ABS	BMW Motorrad ABS (partly integral)
Seat Height	850 mm
Wet Weight	244 kg
