BMW R 1200GS 2016 User Manual

Multifunction switch,
left
1 Headlight flasher and high-
beam headlight ( 54)
2 with cruise control
OE
Cruise-control system
( 77).
3 Hazard warning lights sys-
tem ( 56)
4 ABS ( 63)
ASC ( 65)
with riding modes Pro
OE
DTC ( 66)
5 with Dynamic ESA
OE
Dynamic ESA adjustment
options ( 67)
6 with LED auxiliary head-
light
OA
LED auxiliary driving lamp
( 55).
7 Turn indicators ( 56)
8 Horn
9 Multifunction display
( 57)
2
15
z Overviews

BMW R 1200GS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	125 hp (92 kW) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Tire	120/70 R 19
Rear Tire	170/60 R 17
Length	2, 210 mm
Width	953 mm
Height	1, 450 mm
Wheelbase	1, 507 mm
Fuel Capacity	20 liters
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Transmission	6-speed
Clutch	Hydraulically operated wet clutch
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminum single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual 305 mm discs, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston floating caliper
ABS	BMW Motorrad ABS (partly integral)
Seat Height	850 mm
Wet Weight	244 kg
