18
Step 1a Insert the tabs of four Rail Support (QX1M) in
the slots of the Frame Side Support (QX5M) and
secure each with two M4 x 16 Machine Screws (H14)
and Nuts (H15).
Step 1b Repeat to complete the other Side
Frame Support
