39
QY8
2
Required Hardware
Part #
Description
Qty
H95
M6 x 35
Machine
Screws
4
H18
M6
Locknuts
4
H40
Eccentric
Spacer
2
H41
Eccentric
Washer
2
H42
Bearing
Fender
Washer
6
H44
SG20U
Bearing
4
H57
Bearing
Retainer
Washer
3
H98
M4 x 20
5
H47
M4 Lock
Nut
5
