59
Gantry Assembly
Required Wood Components
Part #
Description
Qty
QG1M
Gantry
Frame
1
QG2
Gantry
Side
Support
4
QG3
Gantry
Cross
brace
4
QG4
Y Rail
Support
5
QG5
Controller
Mount
1
QG6
Gantry
Back Brace
2
QG8M
Gantry
Top/Bottom
Brace
2
QG9
Gantry
Side
2
