Z Spindle Mount Assembly:
Required Wood Components
Part #
Description
Qty
QZ1
Back Frame
1
QZ2
Side Support
2
QZ3
Top Brace
1
QZ4
Top Spindle Mount
1
QZ5
Inner Spindle Mount
1
QZ6
Mid Spindle Mount
2
QZ7
Outer Spindle Mount
2
