88
Final Assembly
Required Wood Components
Part #
Description
Qty
QR1
XY Rail Stop
6
QR3
XY Belt Retainer
12
Required Hardware
Part #
Description
Qty
H53
Stress Proof Steel XY-
Rail (24.75”)
2
H14
M4 x 16 Machine Screw
18
H98
M4 x 20 Machine Screw
12
H47
M4 lock Nut
12
H15
M4 Nut
18
H48
M5 x 30 Machine Screw
6
H93
M5 Square Nut
6
