BOCI BLT441 - Bus System

BLT441 Product Manual
7
4.1 Bus system
Hypcut
IPC
master
station
Slave Station
HyPanel
BCS210E
Power
supply 220V
AC
BLT421 cutting head installation
wiring diagram

Notice:
 The above wiring operations should only be performed by
trained and professional personnel.

When the cutting head is connected to the BCS210E, the
BCS210E must be powered off.
BOCI
