BLT441 Product Manual
2
1.2 Technical parameters
Cutting head BLT441
Laser wavelength: 1030-1090nm
Laser power: ≤15kW
Fiber interface:
Q+、QD、QBH、ADD
Spot magnification: M=1.5/2.0 (100:150/100:200)
Focus adjustment range: ±50mm (optical ratio 1:2 100:200)
NA: Max.0.13 at Fc100
Centering adjustment range: ±1.5mm
Focus acceleration: 7.5m/s²
Cutting gas interface: ø10, maximum 25bar (2.5Mpa)
Nozzle cooling gas connection: ø6, maximum 5bar (0.5Mpa)
Water cooling interface: ø8, maximum 5bar (0.5Mpa), minimum flow 2.0l/min
Operating temperature: 5～55℃
storage temperature: -25～+55 ℃
size: 404x122
weight: About 5.5kg
Notice:
To avoid damage to the cutting head during storage and transportation, pay attention to
the following:
The cutting head should be stored within the allowable temperature and humidity
range.
Avoid storage in and near magnetic fields such as permanent magnets or strong
alternating fields.
Avoid collision of the cutting head.
