Bodet Scorepad User Manual

12
Change the time
To change the time on the scoreboard:
1) Go to the general menu by clicking on
.
2) In the display section, click on
TIME/DATE.
3) Under settings, click on TIME/DATE, then change the time.
Lists of settings for each menu type
1) Access the main menu by clicking
.
Headings Settings Descriptions Main menu
Menu
Advanced
parameters
Technician
menu
(code: 4934).
Sport and clubs
Keyboard sport list
Displays the list of sports you want to appear on the
home screen (8 sports favourites)
- - √
System
Version (VER) View information about the keyboard version.
√ √ (update) √ (update)
Keyboard and score-
board test
Test the scoreboard display.
Test sequence:
1) Display shows the panel number on the main panel.
2) Display shows the panel's EPROM version.
3) Display shows the ribbon cable number for each
module (ashing).
4/ Display shows the address of each module on the
ribbon cable.
5) Display shows all LEDs of all modules (also possible
using dip-switch 3 on the board).
6/ All modules become black.
√ √ √
Back to factory prog*
Reload factory congurations and reset the sports set-
tings.
- -
√
Language Change the language of the keyboard
√ √ √
Display
Time / Date
Displays and sets the time and date of the keyboard
and the scoreboard(s) (from 1 to 6).
Option:
Time display mode: the scoreboard's time display is al-
ways on
ECO time display mode: 12 am. / 6 am. (the scoreboard
displays the time but turns o󰀨 from 12 am. to 6 am.)
OFF: the scoreboard is o󰀨 (all black)
√ √ √
Communication and connectivity
Communication
Communication status on the scoreboard(s):
- Enter the name for each scoreboard (24 characters
max)
- Choose the type of communication between the
keyboard and the scoreboard(s): scoreboard range,
wired, HF radio
- Choose the installation number
- Choose the number of the transmission channel
-
√ √
Duplicate HDMI
Duplicate the Scorepad keyboard screen's display to an
HDMI-connected LCD screen
-
-
√
Local network
Use the ON/OFF button to activate the function: Sport
BUS protocol sent for the TV display
-
-
√
Communication pro-
tocols
Create a communication protocol by lling in the pa-
rameters
- -
√
USB
Load players, teams, team logos. This option also al-
lows you to save a game's information and import/save
the congurations by sport or licence key (WhoIAm)
-
-
√
