Product description 2.1 Technical data
Page 18 Operating instructions for S 40-3...S 150-3 series screw compressors
Technical data S 101-3...S 150-3, part 2
Type S 101-3 S 125-3 S 150-3
Oil filling quantity
Oil receiver volume [gallon] 31.70 31.70 31.70
Total oil filling quantity [gallon] 17.17 17.17 17.17
Oil topping up quantity
between min. + max. [gallon] 2.64 2.64 2.64
Intake air temperature
– min. [°F] + 41 + 41 + 41
– max. [°F] + 104 + 104 + 104
Air cooling
Cooling air requirement
– free-standing installation [cfm] 11772 18834 18834
– with supply and exhaust duct [cfm] 5886 9417 9417
– free fan compression [Pa] 60 60 60
Water cooling
Cooling air requirement
– free-standing installation [cfm] 2000 2000 2000
– with supply and exhaust duct [cfm] 1000 1000 1000
Required cooling water quantity
– delta t = 15 K [cfm] 2.41 2.88 3.53
– delta t = 30 K [cfm] 1.20 1.44 1.77
Max. cooling water quantity [cfm] 5.3 5.3 5.3
Cooling water inlet temperature
– min. [°F] + 41 + 41 + 41
– max. [°F] + 86 + 86 + 86
Cooling water outlet temperature
– max. [°F] + 113 + 113 + 113
Cooling water pressure
– min. [psig] 30 30 30
– max. [psig] 145 145 145
Operating pressure sensor
1
)
1)
Compressors for other operating pressures p
min
= p
max
–15 psig.
(factory settings)
– p
max
= 100 psig: Switch-off press. p
max
[psig]
100 100 100
Switch-on press. p
min
[psig]
85 85 85
– p
max
= 115 psig: Switch-off press. p
max
[psig]
115 115 115
Switch-on press. p
min
[psig]
100 100 100
– p
max
= 125 psig: Switch-off press. p
max
[psig]
125 125 125
Switch-on press. p
min
[psig]
110 110 110
– p
max
= 150 psig: Switch-off press. p
max
[psig]
150 150 150
Switch-on press. p
min
[psig]
135 135 135
– p
max
= 190 psig: Switch-off press. p
max
[psig]
190 190 190
Switch-on press. p
min
[psig]
175 175 175
Safety valve
Activation pressure at:
– p
max
= 100 psig [psig]
160 160 160
– p
max
= 115 psig [psig]
160 160 160
– p
max
= 125 psig [psig]
160 160 160
– p
max
= 150 psig [psig]
160 160 160
– p
max
= 190 psig [psig]
203 203 203
