Operating instructions for S 40-3...S 150-3 series screw compressors Page 19
Product description 2.1 Technical data
Technical Data SF 60-3...SF 150-3, part 1
Type SF 60-3 SF 100-3 SF 150-3
Dimensions
- Height (silenced) [inch] 57.0 57.2 69.3
- Height (super silenced) [inch] 76.5 76.7 88.9
- Width (silenced/super silenced) [inch] 65.7 80.5 95.1
- Depth [inch] 39.4 41.9 51.8
Weight
– silenced [lbs.] 2394 3060 4850
– super silenced [lbs.] 2460 3170 4982
Air cooling
Max. sound pressure level [±3 dB(A)]
– silenced / super silenced [dB(A)] 74 / 72 80 / 73 79 / 74
Measurement surface
– silenced / super silenced [dB(A)]
15 / 16 16 / 17 17 / 18
Sound power level
– silenced / super silenced [dB(A)] 89 / 88 96 / 90 96 / 92
Water cooling
Max. sound pressure level [±3 dB(A)]
– silenced / super silenced [dB(A)] 73 / 71 79/ 72 78 / 73
Measurement surface
– silenced / super silenced [dB(A)] 15 / 16 16 / 17 17 / 18
Sound power level
– silenced / super silenced [dB(A)] 88 / 87 95 / 89 95 / 91
Compressor
Max. final compression temperature [°F] + 230 + 230 + 230
Volume flow according to
ISO 1217 appendix C at:
– p
max
= 100 psig [cfm]
58.24 – 269.10 119.79 – 474.70 172.13 – 682.58
– p
max
= 115 psig [cfm]
55.79 – 257.76 114.05 – 451.97 163.84 – 649.70
– p
max
= 125 psig [cfm]
55.79 – 257.76 114.05 – 451.97 163.84 – 649.70
– p
max
= 150 psig [cfm]
50.85 – 230.57 101.69 – 386.64 150.77 – 575.55
– p
max
= 190 psig [cfm]
42.02 – 195.97 88.63 – 335.80 119.70 – 501.40
Drive motor
Rated power [Hp] 60 60 60
Rated speed
– 60 Hz [rpm] 3600 3600 3600
Protection type IP TEFC TEFC TEFC
ISO-class F F F
Electrical connection
Mains voltage compressor
1)
[V]
1)
Standard equipment. Mains voltages and frequencies are specified on a plate in the switch cabinet.
460 460 460
Frequency
1)
[Hz]
60 60 60
Fuse protection for 460 V
2)
[A]
2)
Use fuse RK 5 only. The fuse values change in the case of other mains voltages and frequencies.
90 150 200
Fuse protection for 575 V
2)
[A]
---
