BT50/BT60/BT65 BOMAG 11
Mixing table
Fig. 2
•
To mix the gasoline with the oil pour both
substances into a clean bowl and shake it well
for approx. 1 minute (Fig. 2). Do not fill the
mixing vessel completely.
Fig. 3
•
Tank contents max. 3,0 Litres.
•
Close the shut-off valve
•
After filling close the filler cover tightly (Fig. 3).
or
Fig. 4
•
estimate the fuel quantity in the tank
•
Unscrew the filler cover and and stand it upside
down into the recess in the tank (Fig. 4).
•
If 1 litre is required fill the measuring vessel up
to the lowest mark (approx. 20 ml) with two-
stroke engine oil and pour it into the tank.
•
Fill the tank up with standard grade gasoline.
The second mark on the measuring vessel (ap-
prox. 40 ml oil) is enough for 2 litres of fuel.
The upper edge of the measuring vessel (approx.
60 ml oil) is enough for 3 litres of fuel.
Operation
