Boneco H680 User Manual

30
en
FILTER HOLDER
1. Remove the filter holder.
2. Clean the filter holder with a damp cloth.
FAN BLADE
Never remove the retaining screw in order to take off
the fan blade! A weight imbalance during reassembly
could cause excessive noise or could even damage
the motor.
1. Clean the fan blades with a damp cloth.
HOUSING
1. Clean the inside of the housing with a damp cloth, hot
water and dishwashing detergent.
GENERAL CLEANING (CONTINUED)

Boneco H680 Specifications

General

Noise level	51 dB
Air purify rate	205 m³/h
Number of speeds	-
Humidifier function	Yes
Water tank capacity	10 L
Humidification capacity	1000 ml/h
Suitable for room area up to	150 m²
Suitable for room volume up to	375 m³
Filtering capability	Fine dust, Pollen, Viruses
Product color	Black, White
AC input voltage	100 - 240 V
AC input frequency	50-60 Hz
Power consumption (max)	30 W

Weight and Dimensions

Depth	347 mm
Width	435 mm
Height	490 mm
Weight	10400 g
