BONFIGLIOLI ACTIVE Cube ACU 401-33

Operation mode 490
Function
1001 –
Single evaluation
with reference track
Two-channel speed sensor with recognition of direc-
tion of rotation via track signals A and B, reference
track via digital input S6IND. One signal edge is eval-
uated per division mark.
1002 –
Double evaluation
with reference track
Two-channel speed sensor with recognition of direc-
tion of rotation via track signals A and B, reference
track via digital input S6IND. Two signal edges are
evaluated per division mark.
1004 –
Quadruple evalua-
tion with reference
track
Two-channel speed sensor with recognition of direc-
tion of rotation via track signals A and B, reference
track via digital input S6IND. Four signal edges are
evaluated per division mark.
1011 –
Single evaluation
with sense of rot.
without sign with
ref. track
One-channel speed sensor via track signal A; the ac-
tual speed value is positive. The reference track is
connected to digital input S6IND. One signal edge is
evaluated per division mark. The digital input S4IND is
available for further functions.
1012 –
Double evaluation
with sense of rot.
without sign with
ref. track
One-channel speed sensor via track signal A; the ac-
tual speed value is positive. The reference track is
connected to digital input S6IND. Two signal edges
are evaluated per division mark. The digital input
S4IND is available for further functions.
1031 –
Single evaluation
sense of rot. via
contact with ref.
track
One-channel speed sensor via track signal A. The
actual speed value is positive for signal “Low” and
negative for signal “High” at digital input S4IND. One
signal edge is evaluated per division mark. The refer-
ence track is connected to digital input S6IND.
1032 –
Double evaluation
sense of rot. via
contact with ref.
track
One-channel speed sensor via track signal A. The
actual speed value is positive for signal “Low” and
negative for signal “High” at digital input S4IND. Two
signal edges are evaluated per division mark. The
reference track is connected to digital input S6IND.
1101 –
Single evaluation
inverted with refer-
ence track
Same as operation mode 1001. The actual speed val-
ue is negative.
1102 –
Double evaluation
inverted with refer-
ence track
Same as operation mode 1002. The actual speed val-
ue is negative.
1104 –
Quadruple evalua-
tion inverted with
reference track
Same as operation mode 1004. The actual speed val-
ue is negative.
1111 –
Single evaluation
inv. with sense of
rot. without sign
with ref. track
Same as operation mode 1011. The actual speed val-
ue is negative.
1112 –
Double evaluation
inv. with sense of
rot. without sign
with ref. track
Same as operation mode 1012. The actual speed val-
ue is negative.
1131 –
Single evaluation
inv. sense of rot. via
contact with ref.
track
One-channel speed sensor via track signal A. The
actual speed value is negative for signal “Low” and
positive for signal “High” at digital input S4IND. One
signal edge is evaluated per division mark. The refer-
ence track is connected to digital input S6IND.
1132 –
Double evaluation
inv. sense of rot. via
contact with ref.
track
One-channel speed sensor via track signal A. The
actual speed value is negative for signal “Low” and
positive for signal “High” at digital input S4IND. Two
signal edges are evaluated per division mark. The
reference track is connected to digital input S6IND.
06/13 Operating Instructions ACU 129
